营口辽河机械厂,是自行开发,研制,生产I、II类压力容器及各种弯头,三通,异径管,法兰,封头,管帽等产品的专业化制造厂,产品广泛应用于石油,化工,冶金,制药,造船,电力,水利,纺织等行业,年生产能力可达30000吨.

生产范围如下:
各种标准生产的碳钢、不锈钢、合金钢管件及法兰．
一．对焊管件：
1..冷成型和热成型：
　无缝管件和有缝管件
2..标准：DIN, ANSI, JIS, MSS, BS及非标准
3..尺寸：
弯头:1/2”---40” 无缝
     16”----48” 单缝
     16”-----72” 焊缝
     54”-----100” 虾节式
     任何小于180度、SR,LR、异径弯头
     壁厚:从sch5s到4”厚
三通: 1/2”----80”.OD.
      等径三通
      异径三通
      挡条三通
      多支口三通
      四通
         大小头: 1/2”---80”
                 同心,偏心
         弯管: 3”---64”
         4”以上的3D/5D/7D/10D 弯管

管帽/封头:1/2”-120”

二．锻造法兰
1..标准：ANSI, DIN, JIS, BS, …
2..尺寸：½”~100＂
3.材质：碳钢、不锈钢、合金钢等.

我厂在"综合众智,求精务实"的办厂针指导下,发展迅速,已具规模.我们感谢多年来关心支持我厂的各界朋友和国内上的合作伙伴,请新老朋友光临我厂,我们将竭诚为您服务.



   Yingkou Liaohe Machinery Factory

Yingkou Liaohe Machinery & Pipe fittings Co.Ltd., which is the original Yingkou Liaohe Machinery Factory, is one of the experienced manufacturers & Exporters, Specialized in producing and exporting all kind of container of pressure & Pipe Fittings, Including elbows, tees, caps, reducers, flanges and etc. According to International Standards such as ANSI, BS, JIS, DIN, API, etc., under the Quality system of ISO9001: 2000 and PED
The production ability as follow:
Elbows:
1/2”-40” Seamless by mandrel
16”-48” Single seam by mandrel
16”-72” Welded by two halves
54”-100” Miter Elbows
       Any degree upto 180°
       SR-LR-Reducing-3D 90°
       Sch5S through 4” wall
Tees:
     1/2”-80” O.D.
     Fully extruded outlet
     Reinforced outlet
     Reducing
     Barred Tees
     Tees with multiply outlets
     Cross
Reducers:
1/2”-80”
Bell type, Con/Ecc
Long reducer
Round to square

Cap and heads:
1/2”-120”
Pressure vessel oval head
Pressure vessel dish head
Silencer F&D heads

Induction Bends:
3”-64” through 4” wall any radius 3D/5D/7D/10D

Material :
Carbon steel: A234 WPB, WP5, WP11
Low Temp: A420 WPL6,WPL9
High Yield: A860 WPHY 42,46,52,60
Stainless steel: A403 WP304/L, 316L
Duplex: S32205/S31803


Yingkou Liaohe Machinery & Pipe fittings Co.Ltd is especially strong in producing the other products as per the customers' special requirements & designs. We are under the Spirit of "Quality First, Customer Highest, Service Excellent", Yingkou Liaohe Machinery Factory is sincerely hoping to set up a successful & long term Cooperation relationship with customers from all over the world: Step by Step.
